− 33 −

GERMAN FRENCH ITALIAN SPANISHENGLISH

Installing the speaker grilleInstalling the speaker grille

󰝠Grille



 Install the grille as shown in the illustration.



TD510MK2 only



 Install the plugs as indicated.

󰝟

Speaker

󰝟

Speaker

󰝣Plugs X5

･ The grille may be attached when the speaker is not

in use or at the users discretion.

･ Clip the edge of the grille to secure it.

Tip
