− 2 −

ENGLISH GERMAN FRENCH ITALIAN SPANISH



 Remove the base cover.



 Lift up the speaker to remove it from the speaker arm.

󰝟

Speaker

󰝟

Speaker

Speaker base

Speaker arm



 Stand the speaker upright.



 Remove the safety cable from the speaker base.

･ The speaker is heavy, so hold it firmly while removing

it from the speaker arm.

･ After removing the speaker, place it on a surface that

will not mark it or allow it to roll around.

Caution

Speaker base cover

Screw

Screwdriver

Remember to retain the screw as it will be used later.

Tip

Safety cable
